Print

• Printing Technology: PrecisionCore Micro TFP printhead featuring Nozzle Verification Technology and variable-sized droplet control
• Ink Type: UltraChrome PRO12 aqueous pigment ink; 12-color ink set
• Ink Colors: PK, C, VM, Y, LC, Lm, GY, MK, LG, LGY, O, G
• Nozzle Configuration: 9,600 nozzles (800 nozzles x 12 colors)
• Maximum Resolution: 2400 x 1200 dpi
• Minimum Ink Droplet Volume: 3.5 picoliters
• Print Speeds:
  • Draft mode: 1,314 ft²/hr
  • Production mode: 720 ft²/hr
• Printer Language/Drivers:
  • Standard: Epson ESC/P® raster photographic drivers
  • Optional Expansion Unit: Adobe® PostScript® 3, Adobe PDF 1.7
• Memory: 6GB

Epson Replacement Ink Packs

• Ink packs are not included and must be purchased separately to initialize the printer.
• 1.6 L per color x 12 colors total (ink sold separately)
• This printer is designed for use with Epson genuine packs and ink only, not third-party packs or ink.

Media Handling

• BorderFree® Sizes: 64", 60", 54", 44", 40.5", 36", 33.1", 28.7", 24", 23.4", 20", 17", 16.5", 13", 11.8", 10"
• Maximum Printable Length: 529 ft
• Maximum Media Diameter: 7.48" with Auto Take-Up Reel Unit option
• Maximum Roll Weight: 66 lbs with Auto Take-Up Reel Unit option
• Maximum Roll Diameter: 6.6"
• Roll Width: 8" to 64"
• Roll Paper Thickness: 0.08 mm to 1.5 mm
• Roll Paper Remaining: Barcode management
• Minimum Margins (Roll Paper):
  • Top: 3 mm; bottom/right/left margins, 14 mm bottom margin
• Minimum Margins (Cut Sheet):
  • Top: 3 mm; bottom/right/left margins, 14 mm bottom margin
• Media Input: Single Roll, Cut Sheet (manual feed); Poster board (manual feed)
• Paper Thickness (Manual) (Cut Sheet): 0.08 mm to 0.8 mm
• Paper Width (Cut Sheet): 8.27" to 44"

Printer Interfaces

• SuperSpeed USB, 100Base-TX/1000Base-T; Optional 960GB SSD HD with encryption function

Operating Systems Supported

• Mac® OS X 10.6 or later, macOS® 10.12 - 10.15, 11 or later
• Windows® 10, Windows 8.1, Windows 8, Windows 7, Windows Vista®, Windows 2019/2016/2012 R2/2012/2008 R2/2008

Available Software

• Software and Firmware Updates, Epson Edge Color RIP, Epson Edge Print Layout, Epson Media Installer, Epson Software Updater, Uninstaller

General

• Weight and Dimensions (W x D x H):
  • 107.9" x 34.5" x 45.1" (Printing)
  • 107.9" x 34.5" x 41.5" (Stowed)
• Weight: 494 lbs
• Acoustic Noise Level: Operation: 55 dB; Standby: < 7 dB
• Temperature:
  • Operating: 50° to 95° F (10 °C to 35 °C)
  • Storage: ‑4° to 104° F (‑20 °C to 40 °C)
• Relative Humidity:
  • Operating: 20 % – 80 % (no condensation)
  • Storage: 5 % – 85 % (no condensation)
• Standards and Approvals: NRTL Certified CSA/UL 62368‑1 (United States and Canada) compliant with Class A requirements USA (FCC), Canada (ICES‑003)
• Electrical Requirements:
  • Printer Voltage: AC 100 – 240 V (3.4 A – 1.6 A)
  • Power Consumption:
    • Operating: Approx. 95 W
    • Standby: Approx. 0.3 W
    • Ready: Approx. 40 W
    • Sleep: Approx. 2.2 W
• Country of Origin: China

Eco Features

• ENERGY STAR® qualified
• RoHS compliant
• End-of-life options available
• Epson America, Inc. is a SmartWay® Transport Partner

What's Included

• SureColor P20570 Printer, Stand, Paper Basket, Roll Rests, AC Power Cable, Roll Adapter (x2), Epson Edge Print Pro, Setup Guide, Reinstalled Maintenance Boxes (x3), Additional Maintenance Boxes for Ink Initialization (x2), Dust Cover, Cleaning Supplies; Bulk Ink Delivery System (in a separate box)
• Note: Ink and Media are not included with the printer.

Ordering Information

• SureColor P20570 with Bulk Ink Delivery System — SCP20570SE
• Maintenance Tank — T619300
• Replacement Printer Cutter Blade — C13S210040
• Cleaning Sticks — C13S090013
• Adobe PostScript 3 Expansion Unit — C12C939191
• Automatic Take-Up Reel System — C12C932201
• Additional Roll Media Adapters (pair) — C12C932231
• 960GB SSD Storage Drive — C12C936671

UltraChrome PRO12 Ink (1.6 L)

• Photo Black — T56E120
• Cyan — T56E220
• Vivid Magenta — T56E320
• Yellow — T56E420
• Light Cyan — T56E520
• Vivid Light Magenta — T56E620
• Gray — T56E720
• Matte Black — T56E820
• Light Gray — T56E920
• Orange — T56EA20
• Green — T56EB20
• Violet — T56ED20

Limited Warranty and Service

• Warranty: One-year limited in the U.S. and Canada
• Service: On-Site usually Next Business-Day; toll-free telephone support, Monday through Friday

Epson Preferred^SM Plus Extended Service Plans

• Available only at the time of hardware purchase, for up to a total of 5 years of continuous coverage.
• 1-Year Next-Business-Day On-Site Repair — PSP20570S1
• 2-Year Next-Business-Day On-Site Repair — PSP20570S2
• 4-Year Next-Business-Day On-Site Repair — PSP20570S4
